| General | |||||
| CPU Socket Compatibility |
|
||||
| NZXT CAM Compatible | No | ||||
| Warranty | 5 Years | ||||
| Pump | |||||
| Motor Speed | 3100 ± 310 RPM | ||||
| Rated Power |
|
||||
| Power Connector | 3-pin DC Fan Header | ||||
| Cap | |||||
| # of LEDs | 19 LEDs | ||||
| Cap Diameter | 70.56 mm | ||||
| Cap Height | 64.24 mm (incl. cold plate) | ||||
| Cap Material | Plastic | ||||
| Cold Plate Material | Copper | ||||
| RGB Connector |
|
||||
| Tubing | |||||
| Length |
|
||||
| Tubing Material | CIIR+EPDM Rubber with Nylon Braided Sleeve | ||||
| Radiator | |||||
|
Dimensions (Length x Width x Thick) |
|
||||
| Radiator Material | Aluminum | ||||
| Product Info | |||||
| Model Number |
|
||||
| UPC |
|
||||
| EAN |
|
||||
Included Fans
| Kraken Core RGB 240 | Kraken Core RGB 360 |
| 1 x F240 RGB Core Fan (EV-B) | 1 x F360 RGB Core Fan (EV-B) |
Fan Specs
| F240 RGB Core Fan (EV-B) | |
|
Dimensions (Length x Width x Thick) |
240 x 120 x 26 mm |
| # of Fans per Frame | 2 |
| Speed | 500 - 2400 ± 250 RPM per fan |
| Airflow | 75.05 CFM per fan |
| Static Pressure | 3.07 mm H₂O per fan |
| Noise | 31.9 dBA per fan |
| Rated Power |
|
| Bearing | Fluid Dynamic Bearing |
| Fan Power Connector | 4-pin PWM Fan Header |
| Output LED | 8 LEDs per fan |
| RGB Connector | 5V 3-pin Female Addressable RGB |
| Cable Length | 600 mm |
| Materials | Plastic, Rubber, PCB |
| Life | 60,000 hours |
| F360 RGB Core Fan (EV-B) | |
|
Dimensions (Length x Width x Thick) |
360 x 120 x 26 mm |
| # of Fans per Frame | 3 |
| Speed | 500 - 2400 ± 250 RPM per fan |
| Airflow | 75.05 CFM per fan |
| Static Pressure | 3.07 mm H₂O per fan |
| Noise | 31.9 dBA per fan |
| Rated Power |
|
| Bearing | Fluid Dynamic Bearing |
| Fan Power Connector | 4-pin PWM Fan Header |
| Output LED | 8 LEDs per fan |
| RGB Connector | 5V 3-pin Female Addressable RGB |
| Cable Length | 600 mm |
| Materials | Plastic, Rubber, PCB |
| Life | 60,000 hours |
