The F360 RGB Core (Case Version) fan included with the H5 Flow RGB will include a split cable that can be connected to one of the following two connectors:
- 4-pin NZXT RGB
- Can be connected to an NZXT RGB Controller such as the Control Hub, RGB & Fan Controller, or headers on NZXT motherboards.
- 3-pin 5V Addressable RGB (ARGB)
- Can be connected to a 3-pin 5V ARGB header directly on most motherboards or a dedicated 5V ARGB controller.
If the fan is connected to an NZXT RGB header, it can be controlled via the CAM software by selecting the connected controller and adjusting the fan in the Lighting section. If the fan is connected to 5V ARGB, it will not appear in the CAM software and will instead to be controlled through the motherboard or controller's software. For more information, please refer to your motherboard/controller user's manual.
| Can I connect the 5V ARGB to a 12V RGB header? |
Do not attempt to connect the 5V ARGB header or 4-pin NZXT RGB to 12V RGB or UART connectors! This can cause permanent damage to your PC and/or fan(s). Damage caused by improper installation of the fan is not covered under warranty. |
