| Dimensions | |
| Height (with Feet) | 465 mm (18.31 in) |
| Width | 225 mm (8.86 in) |
| Depth | 430 mm (16.93 in) |
| Weight |
|
| General | |
| Enclosure Type | Compact Mid-Tower |
| Motherboard Compatibility |
|
|
Supports Back Connect Motherboards (BTF, Project Zero, etc.) |
No |
| Included Controller | No |
| RGB Lighting | H5 Flow RGB Only |
| RGB Connection Type | 5V ARGB with pre-installed adapter. |
| Materials |
|
| Warranty | 2 Years |
| Clearance | |
| CPU Cooler Height | Up to 170 mm |
| GPU Length | Up to 410 mm |
| PSU Length | Up to 200 mm |
| Cable Management Clearance | Up to 28.7 mm |
| Top Radiator + Fan Thickness | Up to 55 mm |
| Front I/O Ports | |
| USB 3.2 Type-A | 1 |
| USB 3.2 Gen 2x2 Type-C | 1 |
| 3.5 mm Headset Jack | 1 |
| Expansion Slots | |
| Standard | 7 |
| Vertical | 0 |
| Vertical GPU Mounting Kit Compatible | Yes* * Only compatible with Vertical GPU Mounting Kits dated 2024 or newer. For more information, please see refer to the Vertical GPU Mounting Kit FAQ. |
| Drive Bays | |
| 2.5" | 2 |
| 3.5" | 1 |
| Fan Support | |
| Front |
|
| Top |
|
| Bottom |
|
| Rear |
|
| Included Filters | Integrated high-performance mesh |
| Radiator Support | |
| Top |
|
| Front |
|
| Product Info | |
| Model Number |
H5 Flow
H5 Flow RGB
|
| UPC |
H5 Flow
H5 Flow RGB
|
| EAN |
H5 Flow
H5 Flow RGB
|
Included Fans
| H5 Flow | H5 Flow RGB | |
|---|---|---|
| Front | 1 x F120Q Airflow Fan (Case Version) |
1 x F360 RGB Core Fan (Case Version) |
| Rear | 1 x F120Q Airflow Fan (Case Version) |
1 x F120Q Airflow Fan (Case Version) |
Fan Specs
| F120Q Airflow Fan (Case Version) | |
| Speed | 1,350 ± 150 RPM |
| Airflow | 60.2 CFM |
| Static Pressure | 1.05 mm - H₂O |
| Noise | 24.1 dBA |
| Fan Connector & Type | 3-pin DC |
| F360 RGB Core Fan (Case Version) | |
| Speed | 1,700 ± 200 RPM |
| Airflow | 50.1 CFM |
| Static Pressure | 1.27 mm - H₂O |
| Noise | 23.3 dBA |
| Fan Connector & Type | 3-pin DC |
| # of LEDs | 8 per fan (Hub-lit) |
| RGB Connector Type | 4-pin NZXT RGB or 3-pin 5V Addressable RGB |
