| Dimensions | |
| Height (with Feet) | 435 mm (17.13 in) |
| Width | 287 mm (11.3 in) |
| Depth | 415 mm (16.34 in) |
| Weight | 9.4 kg |
| General | |
| Enclosure Type | Compact Dual-Chamber Mid-Tower |
| Motherboard Compatibility |
|
|
Supports Back Connect Motherboards (BTF, Project Zero, etc.) |
No |
| Included Controller | No |
| RGB Lighting | H6 Flow RGB Only |
| RGB Connection Type | 5V ARGB with pre-installed adapter. |
| Materials |
|
| Warranty | 2 Years |
| Clearance | |
| CPU Cooler Height | 163 mm (6.42 in) |
| GPU Length | 365 mm (14.37 in) |
| PSU Length | 200 mm (7.87 in) |
| Cable Management Clearance | 91 mm (3.58 in) |
| Top Radiator Thickness | 30 mm (11.18 in)* *Total radiator + fan thickness of ~60 mm, thicker fans and radiator combinations may result in collision issues with motherboard components such as rear I/O, power, and VRM cooling. |
| Front I/O Ports | |
| USB 3.2 Type-A | 2 |
| USB 3.2 Gen 2x2 Type-C | 1 |
| 3.5 mm Headset Jack | 1 |
| Expansion Slots | |
| Standard | 7 |
| Vertical | 0 |
| Vertical GPU Mounting Kit Compatible | Yes* * Only compatible with Vertical GPU Mounting Kits dated 2024 or newer. For more information, please see refer to the Vertical GPU Mounting Kit FAQ. |
| Drive Bays | |
| 2.5" | 2 |
| 3.5" | 1 |
| Fan Support | |
| Front-Right |
|
| Top |
|
| Bottom |
|
| Rear |
|
| Included Filters | Integrated high-performance mesh |
| Radiator Support | |
| Top | Up to 360 mm |
| Rear | Up to 120 mm |
| Product Info | |
| Model Number |
H6 Flow
H6 Flow RGB
|
| UPC |
H6 Flow
H6 Flow RGB
|
| EAN |
H6 Flow
H6 Flow RGB
|
Included Fans
| H6 Flow | H6 Flow RGB | |
|---|---|---|
| Front | 3 x F120Q Airflow Fan (Case Version) |
3 x F120 RGB Core Fan (Case Version) |
Fan Specs
| F120Q Airflow Fan | |
| Speed | 1,200 ± 240 RPM |
| Airflow | 62.18 CFM |
| Static Pressure | 1.05 mm - H₂O |
| Noise | 25.1 dBA |
| Fan Connector & Type | 3-pin DC |
| F120 RGB Core Fan | |
| Speed | 1,300 ± 130 RPM |
| Airflow | 55.17 CFM |
| Static Pressure | 1.27 mm - H₂O |
| Noise | 26.1 dBA |
| Fan Connector & Type | 3-pin DC |
| # of LEDs | 8 per fan (Hub-lit) |
| RGB Connector Type | 4-pin NZXT RGB (5V ARGB Adapter pre-installed) |
